Cast Steel CF8 DN80 PN16 RF Flange Globe Valve

Product Attribute: Product Description:
Nominal Diameter: DN80
Bore: Full Bore
Nominal Pressure: PN16
Material: CF8
Operation: Handwheel
Design Standard: API602/API 623
Test/Inspection: API598
End Connection: RF Flange
Flange standard: ASME/ANSI B16.5
Top Flange: ISO5210 /ISO5211

INFO@TYFLUIDGROUP.COM

Specification

Design and manufacturing	GB12235
Structure length	GB12221
Pressure temperature grade	GB9131 JB/T74 HG20604
Connection flange	JB/T79 GB9113 HG20593-20635
Test and inspection	GB13927 JB/T9092

Product Overview

The product complies with the national standard GB12235, with reasonable structure, reliable sealing, excellent performance and beautiful appearance.
The sealing surfaces of the valve disc and valve seat are made of stellite cobalt-based hard alloy surfacing, which is wear-resistant.
The valve stem has been tempered and surface nitrided, and has good corrosion resistance and scratch resistance.
Various piping flange standards and flange sealing surface types can be adopted to meet various engineering needs and user requirements.
The valve body has a complete range of materials, and the packing and gaskets are reasonably selected according to actual working conditions or user requirements, and can be applied to various pressure, temperature and medium working conditions.
The inverted seal is made of threaded seal seat or body surfacing of austenitic stainless steel. The inverted seal is reliable. Packing replacement and maintenance can be performed without stopping the machine, which is convenient and quick without affecting the system operation.
