nverted Pressure Balance Lubricated Plug Valves

Product Attribute: Product Description:
Nominal Diameter: 2”
Bore: Full Bore
Nominal Pressure: 2500LB
Material: WCB
Operation: lever
Design Standard: API599/API6D
Test/Inspection: API598
End Connection: Flange
Flange Standard: ASME/ANSI B16.5
Top Flange: ISO5210 /ISO5211
PS: We can manufacture valves to customers’ requirements.

INFO@TYFLUIDGROUP.COM

Product Overview

High-Pressure Efficiency: Tailored for effective fluid control in high-pressure settings.
Innovative Design: Unique inverted pressure balance minimizes wear, ensuring smooth operation.
Lubricated for Longevity: Equipped with a lubrication system, enhancing sealing and extending lifespan.
Versatile Applications: Well-suited for diverse industries like chemicals, oil, and pharmaceuticals.
Precision Control: Enables precise fluid management even in challenging conditions.

Valve Details

Plug valve Supplier: Plug valve working principle

When open, fluid enters the valve. A rotatable core inside controls flow by altering passage position. The inverted pressure balance prevents high-pressure impact, balancing pressure and reducing resistance. Lubrication ensures smooth rotation, enhancing sealing and lifespan. Rotating the core effectively controls fluid flow, achieving precise control and shut-off.
Application of Inverted Pressure Balance Lubricated Plug Valve

The Inverted Pressure Balance Lubricated Plug Valve is ideal for various applications, including high-pressure environments such as chemical processing, oil and gas, and pharmaceutical manufacturing. Its innovative design ensures reliable fluid control, making it well-suited for scenarios that demand precision and effective sealing, even in high-temperature conditions.
